Industrial compressed air and gases are today an essential part of all types of production and quality processes. MSL Compressor's ultra-high pressure compressor line is widely used today in all industrial fields, including as a power source, manufacturing process, and control and testing for various process equipment.
| Model | Power(HP) | Capacity(lt/min) | Stage | rpm | Dimensions (mm) | Weight (kg) | ||
| Width | Depth | Height | ||||||
| MSH 1000 EVS | 30(15x2) | 1000(500x2) | 4 | 1070 | 830 | 1390 | 1475 | 750 |
ㆍCompression stage: 4 stage compression
ㆍWorking pressure: 110 bar
ㆍType: Vertical open type (easy to maintain)
ㆍBelt driven
ㆍDischarge range: 1000 Liter/min
ㆍControl: ON/OFF switch, elapsed time meter, power switch
ㆍCompressed gas: Air
ㆍLong-life bearings
ㆍOil pump
ㆍAir-cooled / final pressure gauge
ㆍPower range: 30 HP
ㆍEquipped with safety valves at each stage
ㆍManual drain / single pressure
